Request Information
Unit of Measure

Notes

Disclaimer

 N/A To get the full fitment details go to www.timkeninfo.com.

Specifications

Country of Origin (Primary)

 N/A GB

Full Timken Part Number

 N/A HA590198;A/AM-HUB BRG

Application Summary

 N/A Audi A3 - Wheel Bearing and Hub Assembly [Front FWD] (2006-2008) Volkswagen Eos - Wheel Bearing and Hub Assembly [Front FWD] (2007-2016) Volkswagen Golf - Wheel Bearing and Hub Assembly [Front FWD] (2010-2014) Volkswagen Golf City - Wheel Bearing and Hub Assembly [Front FWD] (2007-2010) Volkswagen GTI - Wheel Bearing and Hub Assembly [Front FWD] (2006-2010) Volkswagen R32 - Wheel Bearing and Hub Assembly [Front AWD] (2008-2008) Volkswagen Rabbit - Wheel Bearing and Hub Assembly [Front FWD] (2006-2009)

National Popularity Code

 N/A C

Description-Short

 N/A HUB UNIT BRG ASSY

Bolt Circle Diameter

 N/A 4.437

Bolt Size

 N/A M12x1.5

Bolt Qty

 N/A 3

Bearing Type

 N/A Ball Bearing

ABS

 N/A Y

Wheel Stud Size (in.)

 N/A M14x1.5

Wheel Stud Qty

 N/A 5

Wheel Studs

 N/A N

Flange Shape

 N/A Triangle

Spline Quantity

 N/A 36

Box Dimensions

Box Height

 N/A 4.44 in

Box Width

 N/A 5.94 in

Box Length

 N/A 5.94 in

Box Weight

 N/A 6.526 lb
