 N/A To get the full fitment details go to www.timkeninfo.com.

Specifications

Country of Origin (Primary)

 N/A IT

Full Timken Part Number

 N/A HA590232;A/AM-HUB BRG

Application Summary

 N/A Volvo XC90 - Wheel Bearing and Hub Assembly [Rear AWD] (2003-2006) Volvo XC90 - Wheel Bearing and Hub Assembly [Rear FWD] (2003-2006) Volvo XC90 - Wheel Bearing and Hub Assembly [Rear Left AWD] (2007-2014) Volvo XC90 - Wheel Bearing and Hub Assembly [Rear Right AWD] (2007-2014)

National Popularity Code

 N/A D

Description-Short

 N/A HUB UNIT BRG ASSY

Bolt Circle Diameter

 N/A 4.229

Bolt Size

 N/A M12X1.75

Bolt Qty

 N/A 4

Bearing Type

 N/A Ball Bearing

ABS

 N/A Y

Wheel Stud Size (in.)

 N/A M14x1.5

Wheel Stud Qty

 N/A 5

Flange Shape

 N/A Trapazoid (Mod)

Spline Quantity

 N/A 36

Box Dimensions

Box Height

 N/A 4.44 in

Box Width

 N/A 5.94 in

Box Length

 N/A 5.94 in

Box Weight

 N/A 8.026 lb
