 N/A To get the full fitment details go to www.timkeninfo.com.

Specifications

Country of Origin (Primary)

 N/A KR

Full Timken Part Number

 N/A HA590506;A/AM-HUB BRG

Application Summary

 N/A Hyundai Elantra - Wheel Bearing and Hub Assembly [Front FWD] (1999-2000) Hyundai Tiburon - Wheel Bearing and Hub Assembly [Front FWD] (1999-2001)

National Popularity Code

 N/A C

Description-Short

 N/A HUB UNIT BRG ASSY

Bolt Circle Diameter

 N/A 4.5

Bearing Type

 N/A Ball Bearing

ABS

 N/A N

Wheel Stud Size (in.)

 N/A M12 X 1.5

Wheel Stud Qty

 N/A 4

Spline Quantity

 N/A 25

Box Dimensions

Box Height

 N/A 4.44 in

Box Width

 N/A 5.94 in

Box Length

 N/A 5.94 in

Box Weight

 N/A 4.645 lb
