Unit of Measure

Specifications

Series

 N/A Industrial

Shaft Size d

 N/A 1 3/16 in

Bearing Type

 N/A Ball Bearing

Bearing Number

 N/A SM1103KS

Seal Type

 N/A Shroud Seal

Housing Construction

 N/A Two-Bolt Pillow Block

Alternate Part Name

 N/A SAL 1 3/16

Dimensions

Dimension A1

 N/A 56.4 mm2.219 in

Base to Center Height H

 N/A 50.8 mm2 in

Total Length L

 N/A 177.80 mm7.000 in

Dimension L1

 N/A 96.8 mm3.813 in

Total Width A

 N/A 54 mm2.125 in

Bolt Hole Spacing J

 N/A 139.7 mm5.5 in

Bolt Hole Width N

 N/A 15.9 mm0.625 in

Bolt Hole Length N1

 N/A 19 mm0.75 in

Foot Height H1

 N/A 17.5 mm0.688 in

Dimension d1

 N/A 44.4 mm1.75 in

Dimension B1

 N/A 48.4 mm1.906 in

Dimension T

 N/A 41.3 mm1.625 in

Basic Load Ratings

Static Load Rating

 N/A 11100 N2500 lbf

Dynamic Load Rating

 N/A 21600 N4800 lbf
